| Modelo | Diámetro de base (A) | Altura de base (B) | Tamaño de tornillo (C y D) | Capacidad de carga | ||
| · 3/4 x 1 3/4″ | ||||||
| MPC-100 | 100 mm | 55 mm | · 5/8 x 1” | 300 KG | ||
| · 3/4 x 2” | ||||||
| · 5/8 x 1 3/4″ | ||||||
| MPC-3*2 | 3” | 2 1/2″ | · 1/2 x 1 3/4″ | 220 KG | ||
| · 5/8 x 1 3/4″ | ||||||
| MPC-3 | 3” | 1 1/2 “ | · 1/2 x 1 3/4″ | 200 KG | ||
| · 1/2 x 1 1/2″ | ||||||
| MPC-2 | 2” | 1 1/2” | · 3/8 x 1 1/2″ | 160 KG | ||
| · M10 x 45 mm | ||||||
| MPC-63 | 63 mm | 68 mm | · 1/2 x 1 3/4″ | 155 KG | ||
| · 1/2 x 1 1/4” | ||||||
| MPC-2*1 | 2” | 1” | · 3/8 x 1 1/4” | 150 KG | ||
| · 3/8 x 1” | 90 KG | |||||
| MPC-40 | 40 mm | 35 mm | · 5/16 x 1” | |||
| · M8 x 25 mm | ||||||
| · M8 x 25 mm | ||||||
| MPC-4022 | 40 mm | 22 mm | · 3/8 x 1” | 60 KG | ||
| · 5/16 x 1” | ||||||
| · 3/8 x 1” | ||||||
| MPC-32 | 32 mm | 32 mm | · 5/16 x 1” | 50 KG | ||
| · M8 x 25 mm | ||||||
| · 3/8 x 1” | ||||||
| MPC-30 | 30 mm | 30 mm | · 5/16 x 1” | 50 KG | ||
| · M8 x 25 mm | ||||||
| · 1/4 x 1” | ||||||
| MPC-25 | 25 mm | 20 mm | · 1/4 x .850” | 35 KG | ||
